SIYI TechnologySIYI- UniRC 7 / 7 Pro Ground Station Smart Controller

SIYI UniRC 7 / 7 Pro Ground Station Smart Controller is a state of the art handheld controller designed to provide seamless control for UAVs, UGVs, USVs, and other robotics applications. This next-generation controller features a 7-inch high-brightness 1080P touchscreen (1600-nit brightness) and dual-frequency redundancy with 2.4 GHz and 5 GHz bands, ensuring robust connectivity and precision control over long distances. With a communication range of up to 40km, 4K 30fps decoding capability, and AES encryption, the UniRC 7/7 Pro offers unmatched reliability and security in demanding environments. Powered by a Qualcomm 8-core CPU with 4GB RAM and 64GB storage, and running on Android 13 OS, this controller is optimized for high performance and intuitive operation.

Equipped with innovative features like a unique sub-joystick for enhanced control, six customizable flight mode buttons, dual-operator capabilities, and active cooling for optimal performance, the UniRC 7/7 Pro is designed to meet the needs of professionals across diverse industries. The quick-release belly bracket and four-antenna design further enhance its stability and signal strength, making it an ideal choice for those in agricultural, surveying, and inspection fields.

Features:

• 2.4 / 5 GHz Dual Frequency Redundancy
• 40 KM Communication Range
• 11 Hours Battery Life
• 7-Inch 1080P Monitor
• Ground Unit Four-Antenna Design Dual Internal Antennas
• Unique Sub Joystick
• Quick-Release Belly Bracket
• Active Cooling
• Dual Operator, Payload Control, Flight Control
• 30W PD Fast Charging
• Qualcomm 8-Core CPU 4GB RAM, 64GB ROM
• Six Flight Mode Buttons
• Air Unit Four-Antenna Design Quick-Release, Detachable
• Quick-Release Battery

Specification:

• Screen: 7" LCD Touchscreen, 1080p, 1600-nit brightness
• Frequency Bands: Dual 2.4 GHz & 5 GHz
• Communication Range: Up to 40 km
• Battery Life: 11 hours, with 30W PD fast-charging support
• CPU: Qualcomm 8-core processor
• RAM/Storage: 4GB RAM, 64GB ROM
• Transmission Bitrate: Up to 65 Mbps
• Video Decoding: 4K at 30fps
• Encryption: AES Encryption
• Ports: Dual LAN, USB, UART
• Power Supply: XT30 port for external power
• Flight Modes: Six customizable buttons
• Antenna Design: Ground and air units with four antennas, dual internal antennas for stable connectivity

Package contains:

UniRC7

UniRC7PRO

1xUniRC7 Ground Unit

2x2.4G Omnidirectional Antennas

1xUniRC7 PRO Ground Unit

2xStandard2.4G Omnidirectional Antennas

1xUniRC7AirUnit

2x2.4G Omnidirectional Antennas

1xUniRC7PROAirUnit

2x2.4G Omnidirectional Antennas

2x5G Omnidirectional Antennas

1 x PX4/ArduPilot Autopilot Data Cable

1 x S.Bus Male Connector Cable

1 x PWM Cable

1 x 30WPDFastCharger (Type-C, US Standard)

1 x PD Fast Charge Data Cable (Type-C to Type-C)

 1 x Type-C to USB-A Adapter

1 x Storage Case

 2 x Quick-Release Belly Supports

1 x 30WPDFastCharger (Type-C, US Standard)

1 x PD Fast Charge Data Cable (Type-C to Type-C)

 1 x Type-C to USB-A Adapter

1 x Storage Case

2 x Quick-Release Belly Supports

1 x Ground Unit Shoulder Strap

1 x Ground Unit Shoulder Strap
