*Last one in stock, will not be replenished as this product now discontinued*
New updated version SF40/C is a long range (0 ... 100 m), laser scanner designed specifically to provide UAVs with SLAM intelligence. Providing UAVs with simultaneous localization and mapping intelligence.
New updated version ... The following enhancements have been made: 1. The red Motor driver PCBA is now internal, making for a more compact and robust design; 2. The unit is fully field upgradeable; 3. We’ve improved the diagnostic functions through the LightWare Terminal program; 4. A USB cable will no longer be provided, only a serial cable, but of course a serial to USB converter can be used. 5. Importantly: we’ve replaced the FPGA with a new type of processor. We hope this will alleviate the resetting issue caused by some power supplies. Please use this new draft manual for the product: https://lightware-optoelectronics.github.io/sf40-docs/ SF40/C is a long range (0 ... 100 m), laser scanner designed specifically to provide UAVs with SLAM intelligence.
Typical applications:
The SF40/C is a laser scanner for which provides UAVs with simultaneous localization and mapping intelligence. With 100 % data saturation at 5 image updates per second, multi-directional collision avoidance is enabled.
| Weight | 270 g (excluding cable) |
| Range | 0 ... 100 m (natural targets) |
| Resolution | 0.12 … 0.03 meters (selectable) |
| Update rate | 1, 2.25 or 4.5 revolutions per second |
| Outputs & interfaces | Serial, two hardwired alarms, servo connections & spare |
| Laser power | 20 W (peak), 11 mW (average), Class 1M |
| Dimensions | 91 mm (height) x 79 mm (largest diameter) |
| Operating temperature | 0 ... 40°C |
| Approvals | FDA: 1630995-000 (2016/09) |
| Optical aperture | 51 mm |
| Beam divergence | 0.2° |
*Last one in stock, will not be replenished as this product now discontinued*
New updated version SF40/C is a long range (0 ... 100 m), laser scanner designed specifically to provide UAVs with SLAM intelligence. Providing UAVs with simultaneous localization and mapping intelligence.
New updated version ... The following enhancements have been made: 1. The red Motor driver PCBA is now internal, making for a more compact and robust design; 2. The unit is fully field upgradeable; 3. We’ve improved the diagnostic functions through the LightWare Terminal program; 4. A USB cable will no longer be provided, only a serial cable, but of course a serial to USB converter can be used. 5. Importantly: we’ve replaced the FPGA with a new type of processor. We hope this will alleviate the resetting issue caused by some power supplies. Please use this new draft manual for the product: https://lightware-optoelectronics.github.io/sf40-docs/ SF40/C is a long range (0 ... 100 m), laser scanner designed specifically to provide UAVs with SLAM intelligence.
Typical applications:
The SF40/C is a laser scanner for which provides UAVs with simultaneous localization and mapping intelligence. With 100 % data saturation at 5 image updates per second, multi-directional collision avoidance is enabled.
| Weight | 270 g (excluding cable) |
| Range | 0 ... 100 m (natural targets) |
| Resolution | 0.12 … 0.03 meters (selectable) |
| Update rate | 1, 2.25 or 4.5 revolutions per second |
| Outputs & interfaces | Serial, two hardwired alarms, servo connections & spare |
| Laser power | 20 W (peak), 11 mW (average), Class 1M |
| Dimensions | 91 mm (height) x 79 mm (largest diameter) |
| Operating temperature | 0 ... 40°C |
| Approvals | FDA: 1630995-000 (2016/09) |
| Optical aperture | 51 mm |
| Beam divergence | 0.2° |
