GremsyGREMSY - AEVO

Aevo is the next generation of heavy-lifting gimbal boasting a sturdy carbon frame construction, high encoder resolution, and high-torque brushless motors to handle massive sensors for industrial uses.

AEVO Manual

Specifications

• Product Name AEVO
• System Type 3-Axis Camera Stabilizer
• Weight 5.8 lbs (2.63kg)
• Construction Carbon & Aluminum
• Input Voltage 24-52VDC
• Connection USB 2.0, CAN, UART, S-bus, Spektrum, PPM, Bluetooth 4.0
• OS Platform Supported Windows 10 or above; macOS 12.0 or above
• Single Operator On/OFF, Lock Mode, Follow Mode, Mapping Mode
• Pan Range No limit
• Tilt Range ±120°
• Roll Range ± 45°

Package contains

• 1 x AEVO Gimbal
• 1 x AEVO Quick Release
• 1 x USB-C Cable
• 1 x PWT Cable
• 2 x Auxiliary Cable
• 2 x COM2/COM3 Cable
• 1 x Sbus Cable
• 1 x Power Supply Cable
• 1 x DJI A3 Cable
• 1 x Allen key 3mm
• 1 x Allen key 2.5mm
• 1 x Allen key 2mm
• 1 x Allen key 1.5mm
• 6 x M4 x 10

LIGHT AND STURDY CARBON CONSTRUCTION - Aevo features a sturdy carbon frame construction and improved mechanical design, which helps to boost the gimbal's rigidity while keeping it as light and compact as possible.

BUILT FOR MASSIVE PAYLOADS- With large camera cage and high-torque brushless motors, Aevo can effortlessly carry massive payloads up to 9 kg, ideal for industrial cameras of HySpex, Specim, iXM series.

OPERATION MODE -Payloads can be installed on either the top or bottom of the gimbal depending on your specific applications.

RELIABLE AND SECURE QUICK RELEASE- Incorporating both mechanics and electronics, Aevo's quick release not only provides a secure way to install the gimbal under your drone, but also enables seamless data transmission throughout the entire system.

360° CONTINUOUS PANNING CAPABILITY- Allowing the camera to instantly capture every possible angle of the object, Aevo boasts a high-speed 360° infinite panning capability.

SUPPORT M600 AND CUSTOM DRONES- Aevo is an easy-to-install camera stabilization designed for M600 and Pixhawk-based drones using its unique dampening system. Click HERE for further information regarding Aevo's damping dimension.

SDK INTEGRATION- Aevo supports SDK and MAVSDK via COM 2 port connection, allowing users to manage the gimbal and seamlessly integrate it into their solutions and applications.
